Lithium-Ion Battery Storage Cabinet
Lithium-Ion Battery Storage Cabinet
Couldn't load pickup availability
Doors have 2 factor latching with 3 x 304 stainless steel slam shut catches on the inside. Plus on the outside - 2 x 304 Stainless Steel latches join the doors together to become one - mitigating the chance of the doors blowing open in a multi - battery explosion .
5 x completely insulated compartments with many adjustable positions. It is possible to remove shelves to fit your larger batteries.
10 x one way vents - made up of a 100mm diameter flame arrestor on the inside wall, then a HotWall filter in the centre of the walls, then louvre exhausts - 5 on each side.
The Hydrogen gases and Hydrogen Fluoride smoke given off when batteries explode, need to escape through a one way vent to prevent pressure build up within the cabinet resulting in the doors blowing open.
Class 9 Misc DG cabinets and Flammable cabinets are not designed for battery storage, they are designed to stop sparks getting into the cabinet : Lithium-ion Battery Cabinets are designed to stop exploding batteries, sparks and extreme temperatures from getting out of the cabinet.
Powder coated with our high-build polyester resin powder for longevity and easy cleaning.
Freight is $85+GST Per Cabinet
| Dimensions | 1800mmHigh x 1100mmWide x 500mmDeep Outside.
1680mmHigh x 1000mmWide x 415mmDeep Inside |
| Capacity | Up to 100 x 5 amp/hr batteries or equivalent ..EG 500 x 1 amp/hr Batteries … EG 1000 x 0.5 amp/hr batteries . Max capacity batteries in total is 500 amp/hrs |
| Weight | 215kg |
| Steel thickness | 1.2mm all around |
| Wall thickness | Walls, doors, top, base and shelves which create the adjustable compartments all have 40mm between the walls and all are sandwiched with 1260 deg HotWall Insulation |
| Extras | Includes Location brackets and fixings to secure the cabinet, also four levelling feet |
| Patent No. | 2023901080 |
| Finish | TSCW powder coated Ral 9003 white with exterior polyester resin powder for easy cleaning |
| Insulation | Extreme Temperature HotWall Insulation . |
| Lock | Flush mounted door handle – locking at three positions with two keys. All latches and catches are made from 304 Stainless Steel with a melting point of 1510 Deg C |
| Packaging | Comes packaged in a poly-foam with corrugated cardboard , Angle cardboard strengthening corners strapped to an integrated pallet with fork positions |
| Vents | 10 x one way exhaust vents , 2 per compartment |
| Shelves | Five adjustable and removable HotWall insulated shelves to mitigate exploding batteries lighting up batteries in above or below compartments |
| Suitable for | Indoor use. Storing your lithium-ion batteries |
| Warranty | Lifetime warranty on the cabinet (does not include wear and tear or damage) |
